- Adopts microcomputer PID control method that can regulates temperature with high accuracy.
- Adopts LCD display superior in visibility.
- Integrates 4-types of timer functions(ON・OFF・ON/OFF・SET) as standard. The program function supports up to 8-steps of temperature/time inputs.
- Operation data can be managed on PC easily by using special software for data communication(included in CD-ROM) and communication cable(option)
- Sample temperature can be controlled directly by using external temperature sensor(option).
- Integrates alarm signal output as standard. The signal can be used to stop another equipment or start reserve system upon emergency.
Spec
- Model number: ND-3HA
- Highest temperature (℃): 350
- Plate size (mm): 400 x 300
- Temperature settings range: Room temperature +10 - 350℃
- Temperature settings: Digital input type
- Temperature distribution width: 4℃ (*temperature distribution width is indoor environment 25℃ (no wind, no load, using internal sensor), Reference value when setting to 200℃. )
- Temperature control system: Microcomputer type PID control system, ON/OFF control system
- Temperature display system: LCD digital display (setting/measurement temperature simultaneous display, heater output bar graph display)
- Internal temperature sensor: K class thermocouple
- Safety device: Self-diagnosis function (Upper or lower limit temperature abnormality detection, heater abnormality detection, sensor abnormality detection), abnormal heating preventive device (thermostat), overcurrent fuse
- Heater capacity: 1890W
- Additional function: Timer function: Setting range/1 minute - 99 hours 59 minutes (1 minute unit), Program function: Number of steps/maximum 8 steps, repeat times/maximum 9999 times, Setting resolution/temperature 0.1℃, time 1 minute, Communication function: PC output (USB), External temperature sensor supported, Upper or lower limit temperature alarm, Alarm signal output, Settings value memory function, Key lock function, Auto-tuning function
- Plate material: Aluminum (ceramic coating)
- Size: 470 x 410 x 101mm
- Power supply: 100VAC 50/60Hz
- Power cord length: Approx 1.4m
- *Demonstration equipment 1-4601-31, 32, 41, 42 are available.
- RoHS3 (EU)2015/863 Certificates can be issued [About RoHS]
-
Package size:490×550×170 mm 13.1 kg
