Features
- Oil-free and clean diaphragm type dry pump with no contamination by oil.
- It is suitable for vacuum applications in rotary evaporators and chromatograms.
- All the contact gas parts are coated with PTFE (tetrafluoroethylene) so they have excellent corrosion resistance.
- With a leak valve, the vacuum level can be adjusted.
- It comes with a pressure gauge, so it's convenient to check the vacuum.
- Original dry vacuum pump with corrosion resistant type.
Spec
- Model number: GM-20S-AC
- Specification: 1 stages
- Achieving pressure: -0.08MPa
- Size (mm): 270 x 130 x 210
- Diaphragm: PTFE (poly tetrafluoroethylene) coating
- Exhaust speed (50/60Hz): 20/24L/min
- Noise: 50dB
- Safety device: Motor overheat protection equipment
- Power supply: 100VAC 50/60Hz
- Power consumption: 200W
- Power cord length: 1.5m
- Connection port: φ6mm hose nipple
- Weight: 7.5kg
-
Package size：200×350×330 mm
