Features
- Resin sheets and molded samples can be made.
- We can perform heat compression molding tests on various materials.
- It operates hydraulically so it can be easily weighted.
- The pressure gauge is a two-needle retention type, so you can check the weighted pressure.
- The hydraulic pressure is measured with a digital pressure gauge.
Spec
- Weight (t): 0 ~ 15
- Size (mm): 560 x 380 (725) x 570
- Heat plate size: 200 x 150 mm
- Heat plate stroke: 0 ~ 90 mm
- Heating temperature: room temperature + 20 ~ 300 degrees C
- Heater capacity: 660 W/2 hot plates
- Temperature control: PID method
- Pressure gauge: Digital display (hydraulic measurement) (Has a peak hold function and uses 006P (9V) batteries.)
- Weight: approximately 71 kg
- Power supply: 100 VAC 50/60 Hz
- Power cord length: 2.5 m (with 3 P plug)
- *Include handles in parentheses
- *Pressure can not be maintained for a long time.
- *It can be custom-made, including hot plate size and stroke change. Please inquire.
- *Wooden packaging (wooden frame, pallet, etc.) is used.
-
*This product might require extra fees.
Package size：720×245×690 mm
