Features
- It is used to measure a certain volume. It is also called a full-volume flask.
- It has a long, narrow neck extending into a flat-bottomed flask and usually has a single line in the neck area.
- Because the diameter of the graduated neck is small, the precision of the scale is higher than that of a graduated cylinder of the same capacity.
- It is used to precisely adjust a certain reagent concentration.
- The scale represents the receiving volume (the volume that is contained) and is displayed by TC, which means received (required). (TC: short for To Contain) The scale represents the volume of water measured at 20 degrees Celsius.
- It is more accurate than JIS standard (R3505) Class A "volume tolerance."
- The outside is brown-dyed for shading.
Spec
- Code number: 020070-50 A
- Material: borosilicate glass
- TS glass flat plug
- overall height: 150 mm
- Capacity: 50 mL
- Color: Brown
- Volume tolerance error: ± 0.05 mL
- Plug (TS TS): 13
- outer diameter: φ 51 mm
- * It is manufactured with higher accuracy than JIS R 3505 (1994) Class A "volume tolerance error".
- RoHS3 (EU)2015/863 Certificates can be issued [About RoHS]
-
Package size：50×50×160 mm 90 g
