Spec
- Capacity (L): 207
- Inner dimensions (mm): 620 x 545 x 584
- Outer dimensions (mm): 700 x 732 (799) x 1107
- Material: Exterior/Plastic baked paint steel sheet, Interior/Stainless steel sheet
- Temperature settings range: 15 to + 50 °C
- Compressor output: 180W
- Refrigerant: R -134 a
- Temperature accuracy: +/1.5 °C (Setting: 5.0 °C, no load) when the refrigerator is ON/OFF controlled, +/0.5 °C (Setting: 37.0 °C, no load) when the heater is proportional controlled.
- Temperature distribution: ±0.5 °C (Set temperature: 37.0 °C, ambient temperature: 20 °C, no load)
- Circulation method: Lower back (Callout) ⇒ Upper back (suction)
- Frost removal method: Heater defrost method (microcomputer control)
- Function: 8 steps, 2 patterns
- Alarm function: door alarm, temperature abnormality, sensor abnormality, over rise prevention, earth leakage breaker
- Operation mode: -
- Power supply: AC100V/50/60Hz/15 A
- Power cord length: 3 m
- Power supply plug : 3P plug with ground (L)
- Maximum Power Consumption (50/60Hz): 595/615
- Weight: about 100kg
- Number of shelf board: 2 pieces
- Internal lighting: fluorescent lamps 15W
- Leg part: Free caster, adjustable feet included
- Measurement hole: φ40mm, silicone rubber plug
-
Package size：750×830×1200 mm 120 kg
